Model – BLACKAIR10D2S-V2
Speaker Size – 10” (261mm)
Peak/RMS Power – 900W/300W
Sensitivity – 85dB
Frequency Response – 30Hz – 1kHz
Impedance – Dual 2Ω
Voice Coil – 3” 4 layer
Mounting Depth – 3” (76mm)
Mounting Diameter – 9” (230mm)
Enclosure Volume – 1 – 5ft3
Recommended Amp – POWERBOX400.1M
Parameter BLACKAIR10D2S-V2 (Series). BLACKAIR10D2S-V2 (Parallel)
Fs 36.14Hz 35.986Hz
Vas 14.433 14.291
Re 3.6Ω 0.9Ω
Qms 5.10 3.785
Qes 1.051 0.935
Qts 0.869 0.750
BL 13.342Tm 7.122Tm
SPL 80dB 80.4dB
Sd 0,034m/2 0,034m/2
Cms 84.726uM/N 83.893uM/N
Mms 228.9g 233.161g
Mmd 225.194g 229.454g
X-Max 8mm 8mm
X-Mech 20mm 20mm
