- Is it a subwoofer? A woofer? A Midbass driver? It's all three.
- Audiofrog’s all new GS8ND2 is deisgned as a shallow mount subwoofer for use in applications in which space is at a premium. Many shallow mount subs are designed to minimize mounting depth, but compromise excursion capability in the process. Often, the sealed box volume requirements are too large to fit the application.
- At Audiofrog, we recognize that the application for a shallow subwoofer is a small sealed box. Small sealed boxes require subwoofers with plenty of excursion potential. The GS8ND2 provides 10mm of linear one-way excursion for great performance in sealed boxes as small as a quarter cubic foot. The GS8ND2 is also a stellar performer in a vented box as small as a half cubic foot.
- For OE replacement applications, the GS8ND2 is also a great choice for underseat enclosures in BMWs, Front-Bass replacements in Mercedes-Benz or in factory-provided vented and sealed boxes in the quarter panels of SUVs. The GS8ND2 will also work in an OE infinite baffle application.
- If you're building a custom system in which you need an 8" midbass or in which there's no room for a subwoofer and the front speakers have to be full range, the GS8ND2 is a great choice.
- How can one little woofer do all of this? It's been carefully designed and engineered. A conventional overhung motor with plenty of excursion ensures great performance in a small sealed box. Carefully chosen free air resonance (Fs) makes building a small vented box with a reasonable port length possible. The copper shorting ring reduces distortion and extends the high frequeny response for smooth and powerful midbass up to 300Hz.
- Simply put, the GS8ND2 does what no other 8" can.
Features:
- Fiberglass Cone - Remains rigid through useable frequency range
- Neodymium Magnet - Reduces mounting depth and weight
- Vented Polepiece and Magnetic Gap - Reduces mechanical noise
- Flat Spider - Reduces distortion
- Copper Shorting Ring - Reduces distortion and improves midbass
Specs:
- Power Handling (Continuous Average): 250 Watts
- Power Handling (Music): 500 Watts
- Recommended Amplifier RMS Power Range: 100 Watts to 400 Watts
- Nominal Impedance: 1 Ohm or 4 Ohm
- Sensitivity (2.83V/1M): 91dB
- Frequency Response (-3 dB): 30Hz - 300Hz
- Xmax (Linear 1-Way): 10mm
Dimensions:
- Mounting Depth: 78mm (3-1/16")
- Mounting Height: 11mm (7/16")
- Overall Diameter: 208mm (8-3/16")
- Cut-Out Diameter: 178mm (7")
- Bolt Hole Circle Diameter: 197mm (7-3/4")
- Basket Displacement: 0.47 Litre (0.017 cu.ft.)
Recommended Enclosures:
- Sealed Box Subwoofer or Midbass: 7-11 Litres ( 0.25-0.4 cu. Ft.)
- Vented Box Subwoofer: 15-21 Litres (0.5-0.75 cu.ft.)
- Infinite Baffle Subwoofer: With 29Hz 12dB/oct. high pass filter
- Infinite Baffle Midbass: With appropriate high pass filter
